Schneider Electric 47163 NT10HA3P fixed installation basic switch

In stock
SKU: 683933
€2,588.60
Into a basketIn the basketGo

Overview

Masterpact NT10HA disconnector, 3p, 1000A, 690 V, fixed installation. Series: Masterpact - Product or component type: Load disconnector - Device abbreviation: Masterpact NT10 - Disconnector name: Masterpact NT10 - Description of poles: 3P - Network connection: AC - Network frequency: 50/60 Hz - Line break performance index: HA - Plus contact indication: yes - Visible break: no.

Property Value
Number of poles: 3.0
Rated uninterrupted current Iu: 1000.0 A
Max. Rated operating voltage Ue at AC: 690.0 V
Design as EMERGENCY STOP device: no
Protection class (IP), front: IP30
Connection type main circuit: Screw connection
Device design: Built-in device, fixed installation technology
Design of the actuating element: Push button
Suitable for floor mounting: yes
Conditional Rated short-circuit current Iq: 35.0 kA
Suitable for front mounting 4-hole: no
Version as maintenance/repair switch: no
Voltage release optional: yes
Suitable for front mounting central: no
Suitable for intermediate installation: no
Suitable for distribution board installation: no
Version as main switch: no
Designed as safety switch: no
Motor drive optional: yes
Lockable: yes

Characteristics

HAB47163 NT10HA3P fixed installation
ManufacturerSchneider Electric
HAN47163
GTIN3303430471639
Connection type main circuitScrew connection
Designed as main switchNo
Designed as an EMERGENCY STOP deviceNo
Designed as a safety switchNo
Designed as a maintenance/repair switchNo
Design of the actuating elementPush button
Conditional rated short-circuit current Iq35.0kA
Rated continuous current Iu1000.0A
Suitable for floor mountingYes
Suitable for front mounting 4-holeNo
Suitable for front mounting CentralNo
Suitable for distribution board installationNo
Suitable for intermediate constructionNo
Device typeBuilt-in device Fixed installation technology
Max. rated operating voltage Ue at AC690.0V
Motor drive optionalYes
Number of poles3.0
Protection class (IP), frontIP30
Voltage release optionalYes
LockableYes
