Schneider Electric HMIBSCEA53D1ESM EVlink 50 Ls Static Load Management

In stock
SKU: 714849
€2,747.94
Into a basketIn the basketGo

Overview

HMIBSCEA53D1ESM - EV Charging Expert - Load management for EVlink charging stations with static control of up to 50 charging stations in max. 10 zones. Operating mode: static, controllable zones: 10, zone level: 3, assignment of VIP charging status via charging card, assignment of VIP charging status to fixed charging point. Consumption analysis of all charging stations, RFID badge management, monitoring via dashboard and remote access to the charging stations. Time-of-use function (definition of full load or partial load times), export of maintenance reports, export of charging data, commissioning of all connected charging stations. Connectivity: connection to the OCPP monitoring (OCPP 1.6 Json), connection to the EcoStruxure support (web services), optional: 3G/4G modem, commissioning via Ethernet cable. Different user profiles, Multiple zones and sub-zones, Compatible charging stations: EVlink Wallbox G4 Smart, EVlink Parking Space 2, EVlink 24 kW DC Fast Charger, EVlink AC Pro, Parking Space 3. Installation: On mounting plate portrait or flat, DIN rail, dimensions WxHxD (mm) 157x150x46, weight 1 kg. Mechanical and environmental properties: IP protection class IP40, operating temperature 0 to 50 °C, storage temperature -20 to 60 °C. Relative humidity 10 to 95% non-condensing, operating altitude max. 2000 m. Electromagnetic compatibility 2004/108/EC, conducted and radiated emissions class A EN 55022, Low Voltage Directive 2006/95/EC, EN 61131-2. Class A Group 1 EN 55011, EN 61000-6-4, EAC, RCM, CE.

Feature Value
Width: 157.0 mm
Energy consumption: 16.0 W
Height: 150.0 mm
Charging current: 2.5 A
Max. Number of controllable charging points: 100.0
With communication interface: yes
Emergency release in case of power failure: no
Depth: 46.0 mm

Characteristics

HABEVlink 50 Ls Static
ManufacturerSchneider Electric
HANHMIBSCEA53D1ESM
GTIN3606489943066
Width157.0 mm
Height150.0 mm
Depth46.0 mm
Schneider Electric HMIBSCEA53D1ESM EVlink 50 Ls Static Load Management
Schneider Electric HMIBSCEA53D1ESM EVlink 50 Ls Static Load Management
