Number of auxiliary contacts as changeover contacts0.0
HABK1D012UCH with KBC1B + label 6-1
HANK1D012UCH
GTIN3389110978629
Connection type main circuitScrew connection
Number of auxiliary contacts as normally open0.0
Number of auxiliary contacts as normally closed0.0
VersionSwitch
Design of the actuating elementLong rotary handle
Rated operational power at AC-3, 400 V1.5kW
Rated operational current Ie at AC-3, 400 V3.3 A
Rated continuous current Iu12.0A
Suitable for floor mountingNo
Suitable for front mountingYes
Suitable for distribution board installationNo
Suitable for intermediate constructionYes
Complete device in housingYes
With zero settingNo
With retraction to zero positionNo
Number of poles2.0
Protection class (IP), frontIP65/IP67
