Schneider Electric NSYOPB6U5F wall mount 6HE W600 D500 fixed 19' door R7035 housing

In stock

SKU: 691183

Price on request

€550.40

€0

Overview

19 inch wall housing with fixed frame, made of sheet steel, powder-coated, RAL 7035 light grey, epoxy polyester. Its protection class IP20, the impact protection IK08, the dimensions are 380x600x500 mm with max. 50Kg load.

Property	Value
Color:	gray
Number of height units (HE):	6.0
Height:	380.0 mm
Width:	600.0 mm
Depth:	500.0 mm
Number of doors:	1.0
Type of ventilation:	without
Protection class (IP):	IP20
With front door:	yes
Profile rail design:	without
Material:	steel
Can be dismantled:	yes
RAL number:	7035.0
With earthing:	no
Surface finish:	powder-coated
With roof panel:	yes
With side walls:	yes
Design:	with fixed frame
Grid dimension:	482.6 mm (19 inches)
Max. load capacity:	50.0 kg
Protection class (NEMA):	1
