Rated operating current Ie at DC-13, 230 V0.27 A
Electronic outputNo
HABXCKD2521G11 universal
HANXCKD2521G11
GTIN3389110312218
Number of safety-related auxiliary contacts0.0
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the electrical connectionCable entry PG
Alignment of the actuatorOther
Rated operating current Ie at AC-15, 230 V3.0A
Housing coatingOther
Width31.0 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsNo
Housing designCuboid
Height94.0 mm
Length30.0 mm
With status displayNo
Switching functionSlow-action switching element and snap-action switching element
Switching function latchingNo
IP protection)IP66/IP67
Ambient temperature during operation-25.0 to 70.0 °C
Housing materialMetal
Forced openingYes
