Rated operating current Ie at DC-13, 230 V0.27 A
Electronic outputNo
HABXCKN2902P20 Art.OEOE SPRG Rol.St.M20
Minimal order20
HANXCKN2902P20
GTIN3389119034173
Number of safety-related auxiliary contacts0.0
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the electrical connectionCable entry (metric)
Alignment of the actuatorOther
Rated operating current Ie at AC-15, 230 V3.0A
Housing coatingOther
Width30.0 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsNo
Housing designCuboid
Height85.0 mm
Length30.0 mm
With status displayNo
Switching functionSnap action contact
Switching function latchingNo
IP protection)IP65
Ambient temperature during operation-25.0 to 70.0 °C
Housing materialPlastic
Forced openingYes
