Schneider Electric XSAV12373 speed monitor

In stock

SKU: 675682

Price on request

€122.99

€0

Overview

XSAV inductive sensor for speed monitoring in cylindrical design M30, switching distance Sn 10mm, speed 120-3000 rpm, power supply 12-48V DC, 2m connection cable

Property	Value
Switching distance:	10.0 mm
Voltage type:	AC/DC
Design of the switching output:	PNP/PNP
Mechanical installation condition for sensor:	flush
Performance level according to EN ISO 13849-1:	without
Immunity to magnetic fields:	immune to magnetic direct and alternating fields
Design of the interface:	without
Design of the switching function:	opener
Type of actuation:	metallic target
Frequency:	800.0 Hz
Length of the sensor:	81.0 mm
Pressure-resistant:	no
Rated control supply voltage DC:	12.0 to 48.0 V
Suitable for safety functions:	no
Sensor diameter:	30.0 mm
Number of semiconductor outputs with signaling function:	1.0
Number of contact-based outputs with signaling function:	0.0
Number of safe semiconductor outputs:	0.0
Number of safe contact-based outputs:	0.0
Design of the interface for safety-related communication:	without
Design of the electrical connection:	radial cable
Explosion protection category for gas:	without
Explosion protection category for dust:	without
Housing design:	cylinder, thread
Housing coating:	nickel-plated
Cascadable:	no
Max. output current at the safe output:	200.0 mA
Supply voltage:	12.0 to 48.0 V
With monitoring function for downstream devices:	no
Housing material:	metal
SIL according to IEC 61508:	without
