Rated operating current Ie at DC-13, 230 V0.1 A
Rated operating current Ie at DC-13, 125 V0.0 A
Rated operating current Ie at AC-15, 24 V0.0 A
Electronic outputNo
Rated operating current Ie at AC-15, 125 V0.0 A
HABZCMD41L5 Miniatur
HANZCMD41L5
GTIN3389110299465
Number of safety-related auxiliary contacts0.0
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the electrical connectionPre-assembled with cable
Alignment of the actuatorOther
Rated operating current Ie at AC-15, 230 V1.5A
Rated operating current Ie at DC-13, 24 V0.0A
Housing coatingOther
Width30.0 mm
Diameter0.0 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsNo
Housing designCuboid
Height52.0 mm
Length16.0 mm
With status displayNo
Switching functionSnap action contact
Switching function latchingNo
IP protection)IP66
Ambient temperature during operation-25.0 to 70.0 °C
Housing materialMetal
Forced openingYes
