Rated operating current Ie at DC-13, 125 V0.55 A
Rated operating current Ie at AC-15, 24 V6 A
Electronic outputNo
Rated operating current Ie at AC-15, 125 V6 A
HAB3SE5162-0CH60-1AJ0
HAN3SE5162-0CH60-1AJ0
GTIN4011209908697
Number of contacts as normally open2
Number of contacts as opener2
Number of safety-related auxiliary contacts2
Rated operating current Ie at DC-13, 24 V3 A
Width of the sensor56 mm
Suitable for security functionsYes
Height of the sensor59.3 mm
Length of the sensor214 mm
With status displayNo
Switching function latchingNo
Protection class (NEMA)12
Ambient temperature during operation-40 to 85 °C
Forced openingYes
