Siemens 5SV3642-4 4-pole type B 25A 300mA 400V residual current circuit breaker

In stock
SKU: 890903
€643.54
Into a basketIn the basketGo

Overview

Residual current circuit breaker, 4-pole, type B, short-time delayed, In: 25 A, 300 mA, Un AC: 400 V Residual current circuit breaker SENTRON 5SV3 for comprehensive protection of people and property against electric shock. The residual current circuit breakers offer reliable safety during installation thanks to the standard anti-reach and touch protection. With the convenient manual slider operation, you can remove the residual current circuit breakers from the top-hat rail or from the busbar assembly without tools. The data matrix code on the device gives you quick access to all technical data in the Siemens Industry Online Support app.The SENTRON protective switching devices can be expanded to include many functions using the consistent accessories from the modular system.Optimal technology for your safety - only from Siemens.

Property Value
Rated voltage: 400 V
Rated current: 25 A
Rated residual current: 0.3 mA
Frequency: 50 Hz
Number of poles: 4
Width in modular spacing: 4
Selective type: no
Residual current type: B
Additional equipment possible: yes
Installation depth: 70 mm
Short-circuit strength (Icw): 10 kA
Surge current strength: 3 kA
Short-time delayed type: yes
With locking device: yes
Ambient temperature during operation: -25 to 45 °C
Connectable conductor cross-section, stranded: 0.75 to 35 mm²
Connectable conductor cross-section, single-wire: 0.75 to 35 mm²

Characteristics

HAB4-pole type B 25A 300mA 400V
ManufacturerSIEMENS
HAN5SV3642-4
GTIN4001869549064
Connectable conductor cross-section solid0.75 to 35 mm²
Connectable conductor cross-section stranded0.75 to 35 mm²
Rated residual current0.3mA
Rated voltage400V
Rated current25A
Width in pitch units4
Installation depth70 mm
Residual current typeB
Frequency50Hz
Short circuit strength (Icw)10kA
Short-time delayed typeYes
With locking deviceYes
Number of poles4
Selective typeNo
Surge current strength3kA
Ambient temperature during operation-25 to 45 °C
Additional equipment possibleYes
