SIMATIC S7, S7-SCL Software Update Service As part of this contract, you will receive all current software versions for one year. The contract is automatically extended by 1 year if it is not terminated 3 months before expiry. Delivery and service period: 1 year from the invoice date Prerequisite for completion: current version of the software S7-SCL is particularly suitable for programming complex algorithms and mathematical functions or for tasks in the field of data processing. S7-SCL combines language elements from high-level language programming, e.g. run loops, alternative branches and jump distributors, with PLC-typical language extensions, such as addressing inputs and outputs or starting and querying times and counters. S7-SCL corresponds to the textual high-level language ST (Structured Text) defined in the IEC 61131-3 standard and meets the base level and the reusability level according to PLCopen. SCL is an elementary component of STEP 7 Professional (TIA Portal).
| Property | Value |
| Suitable for Windows 2003 Server operating system: | no |
| With editor for programming language flowchart: | no |
| Suitable for safety functions: | no |
| Integrated motion function: | no |
| Integrated technological function: | no |
| Integrated positioning function: | no |
| Suitable for Windows Vista operating system: | no |
| With editor for programming language AWL (instruction list): | no |
| With editor for programming language KOP (ladder diagram): | no |
| With editor for programming language FUP (function block diagram): | no |
| With editor for programming language ST (structured text): | no |
| With editor for programming language AS (sequential function chart): | no |
| With editor for manufacturer-specific programming language: | yes |
| Suitable for operating system Windows 9x: | no |
| Suitable for operating system Windows NT: | no |
| Suitable for operating system Windows 2000: | no |
| Suitable for operating system Windows XP: | no |
| Suitable for operating system Windows ME: | no |
| Suitable for operating system Windows CE: | no |
| Suitable for operating system LINUX: | no |
| Suitable for operating system, other: | yes |
| IEC 1131-3 (DIN EN 61131-3)-compliant: | yes |
| Diagnostic function integrated: | yes |
| Configuration function integrated: | yes |
| Evaluation function integrated: | yes |
| Project planning function integrated: | yes |
| Data acquisition function integrated: | yes |
| Communication function integrated: | yes |
| Commissioning function integrated: | no |
| Maintenance function integrated: | no |
| Simulation function integrated: | no |
| Analysis function integrated: | yes |
| Suitable for Windows 7 operating system: | yes |
| Suitable for Windows 8 operating system: | no |
