SIMATIC S7, F programming tool S7 Distributed Safety V5.4, upgrade from V5.X to V5.4, upgrade license for 1 user, E-SW, SW and documentation on DVD, Class A, 3 languages (de, en, fr), runs under Windows 7 SP1, Windows 10 Professional, Windows 10 Enterprise, Windows Server 2008 R2 SP1, Windows Server 2012 R2, Windows Server 2016, 64-bit operating system required, from STEP 7 V5.5 SP1, Ref, -HW S7-300F/400F/WinAC F Engineering of safety-related applications in conjunction with STEP 7 V5.x. Safety-related and standard programs can not only run on one and the same CPU, they can also be created with the same engineering tools. The safety-related part of the program is created using the standard STEP 7 languages LAD and FBD, as well as the S7 Distributed Safety option package. To make things easier, S7 Distributed Safety provides a command library with TÜV-approved blocks (e.g. emergency stop, two-hand control, muting, door monitoring). You can also create your own blocks. This makes it much easier to reproduce or expand existing projects. To program safety-related applications with controllers of the new generation S7-1200F, S7-1500F, ET 200SP F-CPU and S7-1500 Software Controller F, you need the engineering software STEP 7 Safety (TIA Portal), with which you can of course also program the fail-safe systems S7-300F, S7-400F and SIMATIC WinAC RTX F.
| Property | Value |
| Suitable for operating system Windows 2003 Server: | yes |
| With editor for programming language flowchart: | no |
| Suitable for safety functions: | yes |
| Integrated motion function: | yes |
| Integrated technological function: | no |
| Integrated positioning function: | no |
| Suitable for Windows Vista operating system: | no |
| With editor for programming language AWL (instruction list): | yes |
| With editor for programming language KOP (ladder plan): | yes |
| With editor for programming language FUP (function plan): | yes |
| With editor for programming language ST (structured Text): | no |
| With editor for programming language AS (sequential function language): | no |
| With editor for manufacturer-specific programming language: | yes |
| Suitable for operating system Windows 9x: | no |
| Suitable for operating system Windows NT: | no |
| Suitable for operating system Windows 2000: | yes |
| Suitable for operating system Windows XP: | yes |
| Suitable for operating system Windows ME: | no |
| Suitable for Windows CE operating system: | no |
| Suitable for LINUX operating system: | no |
| Suitable for other operating systems: | no |
| IEC 1131-3 (DIN EN 61131-3) compliant: | yes |
| Diagnostic function integrated: | yes |
| Configuration function integrated: | yes |
| Evaluation function integrated: | yes |
| Integrated project planning function: | yes |
| Integrated data acquisition function: | yes |
| Integrated communication function: | yes |
| Integrated commissioning function: | yes |
| Integrated maintenance function: | no |
| Integrated simulation function: | yes |
| Integrated analysis function: | yes |
| Suitable for Windows 7 operating system: | yes |
| Suitable for Windows 8 operating system: | no |
| SIL according to IEC 61508: | 3 |
