SIMATIC S7, S7-PDIAG Software Update Service As part of this contract, you will receive all current software versions for one year. The contract is automatically extended by 1 year if it is not terminated 3 months before expiry. Delivery and service period: 1 year from the invoice date Prerequisite for completion: current version of the S7-PDIAG software increases the availability of machines and production systems and optimally supports on-site personnel in fault analysis and rectification. S7-PDIAG enables the configuration of process diagnostics for SIMATIC using the programming languages LAD, FBD or STL. Process diagnostics can be used to detect faulty states outside the automation system (e.g. limit switch not reached). In conjunction with SIMATIC HMI display devices and the SIMATIC ProAgent optional package specially tailored to process diagnostics, S7-PDIAG is a powerful tool. PDIAG is available in the TIA Portal via SIMATIC ProDiag with extended functions for the S7-1500.
| Property | Value |
| Suitable for Windows 2003 Server operating system: | no |
| With editor for programming language flowchart: | no |
| Suitable for safety functions: | no |
| Integrated motion function: | no |
| Integrated technological function: | no |
| Integrated positioning function: | no |
| Suitable for Windows Vista operating system: | no |
| With editor for programming language AWL (instruction list): | yes |
| With editor for programming language KOP (ladder diagram): | yes |
| With editor for programming language FUP (function block diagram): | yes |
| With editor for programming language ST (structured text): | no |
| With editor for programming language AS (sequential function chart): | no |
| With editor for manufacturer-specific programming language: | yes |
| Suitable for operating system Windows 9x: | no |
| Suitable for operating system Windows NT: | no |
| Suitable for operating system Windows 2000: | no |
| Suitable for operating system Windows XP: | no |
| Suitable for operating system Windows ME: | no |
| Suitable for operating system Windows CE: | no |
| Suitable for operating system LINUX: | no |
| Suitable for operating system, other: | yes |
| IEC 1131-3 (DIN EN 61131-3)-compliant: | yes |
| Diagnostic function integrated: | yes |
| Configuration function integrated: | yes |
| Evaluation function integrated: | yes |
| Project planning function integrated: | no |
| Data acquisition function integrated: | yes |
| Communication function integrated: | yes |
| Commissioning function integrated: | no |
| Maintenance function integrated: | no |
| Simulation function integrated: | no |
| Analysis function integrated: | yes |
| Suitable for operating system Windows 7: | no |
| Suitable for operating system Windows 8: | no |
