Spelsberg 07422601 KLS 35-SL clamp

In stock

SKU: 761278

Price on request

€10.01

€0

Overview

PE/N terminal for installation in GTA circuit breaker boxes as additional terminals or for replacement requirements, 1 module, grey, 76 A, 2 x 25mm² + 14 x 4mm² for NS 35Dimensions: 58 x 53 x 23.8mm

Property	Value
Number of poles:	1
Color:	grey
Rated voltage:	450 V
Material of the insulating body:	Thermoplastic
Rated current In:	76 A
Operating temperature:	40 °C
Connectable conductor cross-section, single-wire:	0.5 to 25 mm²
Connectable conductor cross-section, multi-wire:	0.5 to 25 mm²
Connectable conductor cross-section, fine-wire with wire end ferrule:	0.5 to 16 mm²
Mounting type:	DIN rail TH35
Design of electrical connection 1:	Screw connection
Design of electrical connection 2:	Spring-loaded connection
Number of terminal points per pole:	16
Flammability class of the insulating material according to UL 94:	V0
End plate required:	no
Explosion-tested version 'Ex e':	no
Transparent:	no
