Spelsberg 22702501 KVR M25-MGM/sw cable gland

In stock

SKU: 760962

Price on request

€2.08

€0

Overview

9394543 KVR M25-MGM/sw cable gland Cable gland Manufacturer article number: 9394543, Manufacturer article name: KVR M25-MGM/sw cable gland

Property	Value
Wrench size:	28 mm
Thread pitch:	1.5 mm
Nominal thread size metric/PG:	25
Suitable for cable diameters:	9 to 16 mm
Protection class (IP):	IP68
Operating temperature:	-25 to 100 °C
Halogen-free:	yes
Thread length:	11 mm
Thread type:	metric
Design:	straight
Color:	black
Material:	plastic
With strain relief:	yes
Surface:	untreated
Hexagon corner dimension:	31.5 mm
Type of seal:	Sealing ring
Impact resistant:	yes
Bending protection:	no
RAL number:	9005
Material quality:	Polyamide (PA)
Nominal thread size in inches NPT/gas pipe thread:	other
Fiberglass reinforced:	yes
With lock nut:	yes
Multiple sealing insert:	no
Flat cable screw connection:	no
Dividable screw connection:	no
Explosion-tested version:	no
For Ex-Zone Gas:	without
For Ex zone dust:	without
Snaps into opening:	no
For armored cables:	no
EMC version:	no
Shielded:	no
