Spelsberg 22942501 KVR M25 LG-MGM cable gland

In stock
SKU: 710454
€2.59
Into a basketIn the basketGo

Overview

Cable gland, IP68, with strain relief, long connection thread, M_ x 1.5mm, with lock nut, polyamide, grey, sealing range 9-16mm, thread length 15mmDimensions: 31.2 x 31.2 x 48mm

Property Value
Wrench size: 28 mm
Thread pitch: 1.5 mm
Nominal thread size metric/PG: 25
Suitable for cable diameters: 9 to 16 mm
Protection class (IP): IP68
Operating temperature: -25 to 100 °C
Halogen-free: yes
Thread length: 15 mm
Thread type: metric
Design: straight
Material: plastic
With strain relief: yes
Surface: untreated
Hexagon corner dimension: 31.5 mm
Type of seal: Sealing ring
Impact resistant: yes
Bending protection: no
RAL number: 7035
Material quality: Polyamide (PA)
Nominal thread size in inches NPT/gas pipe thread: other
Fiberglass reinforced: no
With lock nut: yes
Multiple sealing inserts: no
Flat cable screw connection: no
Dividable screw connection: no
Explosion-tested version: no
For Ex zone gas: without
For Ex zone dust: without
Snaps into opening: no
For armored cables: no
EMC version: no
Shielded: no

Characteristics

Impact resistantYes
Explosion-tested versionNo
Nominal thread size metric/PG25
Fiberglass reinforcedNo
ShieldedNo
Suitable for cable diameter9 to 16mm
Wrench size28 mm
HABKVR M25 LG-MGM
ManufacturerSpelsberg
HAN22942501
GTIN4013902621231
VersionStraight
EMC versionNo
Operating temperature-25 to 100 °C
Thread typeMetric
Thread length15 mm
Thread1.5 mm
Halogen freeYes
With strain reliefYes
SurfaceUntreated
RAL number7035
IP protection)IP68
MaterialPlastic
Material qualityPolyamide (PA)
