Spelsberg URS RK 1-150qmm terminal block, 67065001

Spelsberg URS RK 1-150qmm terminal block, 67065001

In stock

SKU: 482364

Price on request

€49.91

€0

Into a basketIn the basketGo

Overview

Connection terminal, 1-pole, can be connected in series, for single and multi-strand conductors and for laminated flat copper, conversion kit to 5 poles 1-poleDimensions: 31 x 109 x 99mm

Property	Value
Color:	beige
Connectable conductor cross-section, fine-stranded without wire end ferrule:	50 to 150 mm²
Connectable conductor cross-section, multi-stranded:	35 to 150 mm²
Rated voltage:	1000 V
Number of levels:	1
Number of terminal points per level:	2
Rated current In:	309 A
Operating temperature:	-40 to 105 °C
Connectable conductor cross-section, single-wire:	35 to 150 mm²
Connectable conductor cross-section, fine-stranded with wire end ferrule:	50 to 150 mm²
Design of electrical connection 1:	Screw connection
Design of electrical connection 2:	Screw connection
Mounting type:	DIN rail TH35
Flammability class of the insulating material according to UL 94:	V2
End plate required:	yes
Levels bridged internally:	no
Material of the insulating body:	Thermoplastic
Explosion-tested version 'Ex e':	no

Characteristics

HABURS RK 1-150qmm

Manufacturer

HAN67065001

GTIN4013902859313

Connectable conductor cross-section solid35 to 150 mm²

Connectable conductor cross-section stranded35 to 150 mm²

Rated voltage1000V

Rated current In309 A

Operating temperatur-40 to 105 °C

Flammability class of the insulating material according to UL 94V2

Color

Mounting typeDIN rail TH35
