Wago 2006-1203 2-wire through terminal, 6 mm² red

In stock

SKU: 962032

Price on request

€2.51

€0

Overview

2-conductor feed-through terminal, 6 mm² red

Property	Value
QS single-wire:	1 to 10 mm²
QS fine-wire:	0.5 to 10 mm²
QS multi-wire:	0.5 to 6 mm²
Color:	red
QS wire end ferrule:	1.5 to 6 mm²
Rated voltage:	800 V
Levels:	1
Terminal points per level:	2
Rated current In:	41 A
Operating temperature:	105 °C
Connection:	Spring-loaded connection
Design of electrical connection 2:	Spring-loaded connection
Mounting type:	DIN rail TH35
Flammability class of the insulating material according to UL94:	V0
End plate required:	yes
Levels bridged internally:	no
Material of the insulating body:	Thermoplastic
Explosion-tested version Ex e:	yes
Width:	7.5 mm
Height:	57.4 mm
Depth:	32.9 mm
