Wago 2091-1175/000-5000 PCB connector pin 5p lgr 1re 3.5mm

In stock

SKU: 977559

Price on request

€4.06

€0

Overview

1-conductor THT female connector, straight, push-button, Push-in CAGE CLAMP®, 1.5 mm², pitch 3.5 mm, 5-pin, solder pin Ø 1.0 mm, directly printed, 1.50 mm², light gray

Property	Value
Number of plug contact rows:	1
Type of banding:	without
Type of PCB mounting:	Connection contact
Design of the electrical connection:	Solder connection
Mounting type:	soldering
Rated voltage:	160 V
Rated impulse voltage:	2.5 kV
Rated current In:	10 A
Operating temperature:	-60 to 100 °C
Flammability class of the insulating material according to UL94:	V0
Connection pin diameter:	1 mm
Suitable for PCB thickness:	2 mm
Housing color:	gray
Contact design:	pin
Pin length:	3.6 mm
Connector pitch:	3.5 mm
Contact pitch:	3.5 mm
Connector design:	free connector
Overvoltage category:	III
Degree of contamination:	2
Material of the contact coating:	Tin
Material of the insulating body:	Thermoplastic
Angle of circuit board/contact:	90° (vertical upwards)
Connection type:	flexible circuit board connector
Number of poles:	5
