Wago 2091-1324/200-000 10A, 160V, 4p, solder connector LP

In stock

SKU: 979975

Price on request

€3.32

€0

Overview

THR female connector, angled, pitch 3.5 mm, 4-pin, solder pin 0.4 x 0.9 mm, light gray

Property	Value
Number of plug contact rows:	1
Type of banding:	without
Type of PCB mounting:	Connection contact
Design of the electrical connection:	THR connection
Mounting type:	soldering
Rated voltage:	160 V
Rated impulse voltage:	2.5 kV
Rated current In:	10 A
Operating temperature:	-60 to 100 °C
Flammability class of the insulating material according to UL94:	V0
Suitable for circuit board thickness:	2 mm
Housing color:	gray
Contact design:	pin
Length of pin:	3.6 mm
Pitch of connections:	3.5 mm
Pitch of contacts:	3.5 mm
Connector design:	fixed connector
Overvoltage category:	III
Pollution level:	2
Material of contact coating:	tin
Material of insulating body:	thermoplastic
Angle circuit board/contact:	0°/180° (horizontal)
Connection type:	flexible circuit board connector
Number of pins:	4
