Wago 2092-1302/200-000 16A, 320V, 2p, solder connector LP 5mm

In stock

SKU: 977531

Price on request

€1.89

€0

Overview

THR female connector, straight, pitch 5 mm, 2-pin, solder pin 0.4 x 1.3 mm, light grey

Property	Value
Number of plug contact rows:	1
Type of banding:	without
Type of PCB mounting:	Connection contact
Design of the electrical connection:	THR connection
Mounting type:	soldering
Rated voltage:	320 V
Rated impulse voltage:	4 kV
Rated current In:	16 A
Operating temperature:	-60 to 100 °C
Flammability class of the insulating material according to UL94:	V0
Suitable for circuit board thickness:	2 mm
Housing color:	gray
Contact design:	pin
Pin length:	3.6 mm
Connection pitch:	5 mm
Contact pitch:	5 mm
Connector design:	free connector
Overvoltage category:	III
Pollution level:	2
Contact coating material:	tin
Insulating body material:	thermoplastic
Angle PCB/contact:	90° (vertical upwards)
Connection type:	flexible PCB connector
Number of poles:	2
