Wago 2092-1725/200-000 Accessories Terminal block Solder pin strip

In stock

SKU: 965995

Price on request

€0.85

€0

Overview

THR pin header, solder pin Ø 1.4 mm, angled, pitch 5 mm, 5-pin, black

Property	Value
Number of plug contact rows:	1
Type of banding:	without
Type of PCB mounting:	Connection contact
Design of the electrical connection:	THR connection
Mounting type:	soldering
Rated voltage:	320 V
Rated impulse voltage:	4 kV
Rated current In:	16 A
Operating temperature:	-60 to 100 °C
Flammability class of the insulating material according to UL94:	V0
Connection pin diameter:	1.4 mm
Housing color:	black
Contact design:	pin
Length of Pins:	2.4 mm
Pitch of connections:	5 mm
Pitch of contacts:	5 mm
Connector design:	free connector
Overvoltage category:	III
Pollution level:	2
Material of contact coating:	tin
Material of insulating body:	thermoplastic
Angle PCB/Contact:	0°/180° (horizontal)
Connection type:	flexible PCB connector
Number of pins:	5
