Wago 2231-320/102-000 R5.08mm, 20p, 250V terminal block

In stock

SKU: 982546

Price on request

€18.35

€0

Overview

1-conductor female connector, push-button, Push-in CAGE CLAMP®, 2.5 mm², pitch 5.08 mm, 20-pin, with integrated end plate, 2.50 mm², orange

Property	Value
Connectable cable type:	Round cable
Connectable conductor cross-section, single-wire:	0.2 to 2.5 mm²
Connectable conductor cross-section, fine-wire with wire end ferrule:	0.25 to 1.5 mm²
Connectable conductor cross-section, fine-wire without Wire end ferrule:	0.2 to 2.5 mm²
Connectable conductor cross-section, stranded:	0.2 to 2.5 mm²
Number of plug contact rows:	1
Design of the electrical connection:	Spring-loaded connection
Rated voltage:	320 V
Rated impulse voltage:	4 kV
Rated current In:	16 A
Operating temperature:	-60 to 100 °C
Flammability class of the insulating material according to UL94:	V0
Housing color:	orange
Contact design:	socket
With protective conductor:	no
Pitch of the connections:	5.08 mm
Pitch of the contacts:	5.08 mm
Degree of protection (IP), mounted:	IP20
Overvoltage category:	III
Pollution level:	2
Contact coating material:	Tin
Housing material:	Plastic
Insulating body material:	Thermoplastic
Contact material:	Other copper alloys
Angle contact/conductor connection:	180° (horizontal)
Connection type:	Printed circuit board to cable
Number of poles:	20
Housing coating:	uncoated
