Wago 231-167/003-000 1.2x1.2 5mm pin base strip

In stock

SKU: 519432

Price on request

€4.32

€0

Overview

Pin header for terminal blocks, pins 1.2 x 1.2 mm, straight, pitch 5 mm, 7-pin, grey

Property	Value
Number of poles:	7
Colour:	grey
Rated voltage:	320 V
Material of the insulating body:	Thermoplastic
Rated current In:	16 A
Operating temperature:	-60 to 100 °C
Mounting type:	other
Design of electrical connection 1:	spring-loaded connection
Design of electrical connection 2:	spring-loaded connection
Flammability class of the insulating material according to UL 94:	V0
End plate required:	no
Explosion-tested version 'Ex e':	no
Transparent:	no
