Wago 231-241/001-000/105-604 PCB connector pin 11p sw 1re 7.5mm

In stock
SKU: 966329
€4.83
Into a basketIn the basketGo

Overview

THR pin header, solder pin 1.0 x 1.0 mm, straight, pitch 7.5 mm, 11-pin, black

Property Value
Number of plug contact rows: 1
Type of banding: without
Type of PCB mounting: Connection contact
Design of the electrical connection: THR connection
Mounting type: soldering
Rated voltage: 630 V
Rated impulse voltage: 6 kV
Rated current In: 12 A
Operating temperature: -60 to 100 °C
Flammability class of the insulating material according to UL94: V0
Suitable for circuit board thickness: 1.5 mm
Housing color: black
Contact design: pin
Length of pin: 2.4 mm
Pitch of connections: 7.5 mm
Pitch of contacts: 7.5 mm
Connector design: free connector
Overvoltage category: III
Pollution level: 2
Material of contact coating: tin
Material of insulating body: thermoplastic
Angle PCB/contact: 90° (vertical upwards)
Connection type: flexible PCB connector
Number of pins: 11

Characteristics

Rated surge voltage6 kV
Minimal order50 pcs
ManufacturerWago
HAN231-241/001-000/105-604
GTIN4055143378420
Design of the electrical connectionTHR connection
Mounting typeSoldering
Rated voltage630V
Rated current In12A
Operating temperatur-60 to 100 °C
Housing colorBlack
Number of poles11
Connection typeFlexible circuit board connector
Degree of contamination2
Overvoltage categoryIII
