Wago 231-364/108-000 12A, 320V, 4p, solder, or connector

In stock

SKU: 979768

Price on request

€2.71

€0

Overview

THT pin header, solder pin 1.2 x 1.2 mm, straight, threaded flange, pitch 5.08 mm, 4-pin, orange

Property	Value
Number of plug contact rows:	1
Type of banding:	without
Type of PCB mounting:	Connection contact
Design of the electrical connection:	Solder connection
Mounting type:	soldering
Rated voltage:	320 V
Rated impulse voltage:	4 kV
Rated current In:	16 A
Operating temperature:	-60 to 100 °C
Flammability class of the insulating material according to UL94:	V0
Suitable for circuit board thickness:	1.5 mm
Housing color:	orange
Contact design:	pin
Length of pin:	5 mm
Pitch of connections:	5.08 mm
Pitch of contacts:	5.08 mm
Connector design:	free connector
Overvoltage category:	III
Pollution level:	2
Material of contact coating:	tin
Material of insulating body:	thermoplastic
Angle PCB/contact:	90° (vertical upwards)
Connection type:	flexible PCB connector
Number of pins:	4
