Wago 232-183/047-000 PCB connector pin 23p or 1re 5.08mm

In stock

SKU: 968498

Price on request

€18.02

€0

Overview

THT female connector, straight, pitch 5.08 mm, 23-pin, spacer flange, solder pin 0.6 x 1.0 mm, orange

Property	Value
Number of plug contact rows:	1
Type of banding:	without
Type of PCB mounting:	Connection contact
Design of the electrical connection:	Solder connection
Mounting type:	soldering
Rated voltage:	320 V
Rated impulse voltage:	4 kV
Rated current In:	12 A
Operating temperature:	-60 to 85 °C
Flammability class of the insulating material according to UL94:	V0
Suitable for circuit board thickness:	1.5 mm
Housing color:	orange
Contact design:	pin
Length of pin:	5 mm
Pitch of connections:	5.08 mm
Pitch of contacts:	5.08 mm
Connector design:	free connector
Overvoltage category:	III
Pollution level:	2
Material of contact coating:	tin
Material of insulating body:	thermoplastic
Angle PCB/contact:	90° (vertical upwards)
Connection type:	flexible PCB connector
Number of pins:	23
