Wago 232-872/031-000 PCB connector pin 12p or 1re 7.62mm

In stock

SKU: 981261

Price on request

€6.14

€0

Overview

THT female connector, angled, pitch 7.62 mm, 12-pin, mounting flange, solder pin 0.6 x 1.0 mm, orange

Property	Value
Number of plug contact rows:	1
Type of banding:	without
Type of PCB mounting:	Connection contact
Design of the electrical connection:	Solder connection
Mounting type:	soldering
Rated voltage:	630 V
Rated impulse voltage:	6 kV
Rated current In:	12 A
Operating temperature:	-60 to 85 °C
Flammability class of the insulating material according to UL94:	V0
Suitable for circuit board thickness:	1.5 mm
Housing color:	orange
Contact design:	Pin
Length of pin:	5 mm
Pitch of connections:	7.62 mm
Pitch of contacts:	7.62 mm
Connector design:	free connector
Overvoltage category:	III
Pollution degree:	2
Material of contact coating:	tin
Material of insulating body:	Thermoplastic
Angle circuit board/contact:	0°/180° (horizontal)
Connection type:	flexible circuit board connector
Number of poles:	12
