Wago 236-403/334-604/997-405 3p, 24A,320V,0.08-2.5mm² print terminal 5mm

In stock

SKU: 974145

Price on request

€2.39

€0

Overview

THR PCB terminal, 2.5 mm², pitch 5 mm, 3-pole, CAGE CLAMP®, in a belt, bridging option, 2.50 mm², black

Property	Value
Connectable conductor cross-section, single-wire:	0.08 to 2.5 mm²
Connectable conductor cross-section, fine-wire with wire end ferrule:	0.25 to 1.5 mm²
Connectable conductor cross-section, fine-wire without wire end ferrule:	0.08 to 2.5 mm²
Connectable conductor cross-section stranded:	0.08 to 2.5 mm²
Conductor connection type:	Spring-loaded connection
PCB connection type:	THR connection
Number of electrical connections:	3
Number of levels:	1
Type of banding:	without
Type of PCB fastening:	Connection contact
Fastening type:	soldering
Rated voltage:	320 V
Rated impulse voltage:	4 kV
Rated current In:	24 A
Operating temperature:	-60 to 115 °C
Flammability class of the insulating material according to UL94:	V2
Housing color:	black
Height:	13 mm
Pin length:	3.6 mm
Connection pitch:	5 mm
Overvoltage category:	III
Pollution level:	2
Connection surface material:	Tin
Insulating body material:	Thermoplastic
Angle circuit board/conductor connection:	45°/135° (obliquely upwards)
