Wago 253-104/000-012 4p, 17.5A, 320V, or print terminal 5mm

In stock

SKU: 968606

Price on request

€1.67

€0

Overview

2-conductor PCB terminal, 1.5 mm², pitch 5 mm, 4-pin, PUSH WIRE®, 1.50 mm², orange

Property	Value
Connectable conductor cross-section, single-wire:	0.5 to 1.5 mm²
Conductor connection type:	Plug-in terminal connection
PCB connection type:	Solder connection
Number of electrical connections:	4
Number of levels:	1
Type of banding:	without
Type of PCB mounting:	connection contact
Mounting type:	soldering
Rated voltage:	320 V
Rated impulse voltage:	4 kV
Rated current In:	17.5 A
Operating temperature:	-60 to 105 °C
Flammability class of the insulating material according to UL94:	V0
Housing color:	orange
Height:	13 mm
Length of pin:	3.6 mm
Pitch of connections:	5 mm
Overvoltage category:	III
Pollution level:	2
Material of the connection surface:	Tin
Material of the insulating body:	Thermoplastic
Angle circuit board/conductor connection:	other
