Wago 2624-1105/000-004 print terminal 5f 1re black RM=5 spring/solder

In stock

SKU: 975895

Price on request

€4.05

€0

Overview

PCB terminal, 4 mm², pitch 5 mm, 5-pin, Push-in CAGE CLAMP®, 4.00 mm², black

Property	Value
Connectable conductor cross-section, single-wire:	0.2 to 6 mm²
Connectable conductor cross-section, fine-wire with wire end ferrule:	0.25 to 2.5 mm²
Connectable conductor cross-section, fine-wire without wire end ferrule:	0.2 to 6 mm²
Connectable conductor cross-section, multi-wire:	0.2 to 0.6 mm²
Conductor connection type:	Spring-loaded connection
PCB connection type:	Solder connection
Number of electrical connections:	5
Number of levels:	1
Type of banding:	without
Type of PCB fastening:	Connection contact
Fastening type:	soldering
Rated voltage:	400 V
Rated impulse voltage:	4 kV
Rated current In:	41 A
Operating temperature:	-60 to 105 °C
Flammability class of the insulating material according to UL94:	V0
Housing color:	black
Height:	15.4 mm
Pin length:	4 mm
Connection pitch:	5 mm
Overvoltage category:	III
Pollution level:	2
Connection surface material:	Tin
Insulating body material:	Thermoplastic
Angle circuit board/conductor connection:	0°/180° (horizontal)
