Wago 2706-106/000-009 6p, 41A, 630V print terminal 7.5mm

In stock
SKU: 980469
€8.58
Into a basketIn the basketGo

Overview

PCB terminal, lever, 6 mm², pitch 7.5 mm, 6-pin, CAGE CLAMP®, 6.00 mm², light gray

Property Value
Connectable conductor cross-section, single-wire: 0.5 to 6 mm²
Connectable conductor cross-section, fine-wire with wire end ferrule: 0.5 to 6 mm²
Connectable conductor cross-section, fine-wire without wire end ferrule: 0.5 to 6 mm²
Connectable conductor cross-section, multi-wire: 0.5 to 6 mm²
Conductor connection type: Spring-loaded connection
PCB connection type: Solder connection
Number of electrical connections: 6
Number of levels: 1
Type of banding: without
Type of PCB fastening: Connection contact
Fastening type: soldering
Rated voltage: 630 V
Rated impulse voltage: 6 kV
Rated current In: 41 A
Operating temperature: -60 to 105 °C
Flammability class of the insulating material according to UL94: V0
Housing color: grey
Height: 25.5 mm
Length of the pin: 4.5 mm
Pitch of the Connections: 7.5 mm
Overvoltage category: III
Pollution degree: 2
Material of the connection surface: Tin
Material of the insulation body: Thermoplastic
Angle circuit board/conductor connection: other

Characteristics

Rated surge voltage6 kV
Minimal order25 pcs
ManufacturerWago
HAN2706-106/000-009
GTIN4050821250579
Connectable conductor cross-section solid0.5 to 6 mm²
Connectable conductor cross-section stranded0.5 to 6 mm²
Mounting typeSoldering
Rated voltage630V
Rated current In41 A
Operating temperatur-60 to 105 °C
Housing colorGray
Height25.5 mm
Degree of contamination2
Overvoltage categoryIII
