Wago 714-110/000-047 terminal block 0.2-1.5qmm series 714 8A 8p

In stock

SKU: 975313

Price on request

€6.82

€0

Overview

1-conductor female connector, push-button, 1.5 mm², pitch 3.5 mm, 10-pin, directly printed, 1.50 mm², black

Property	Value
Number of poles:	10
Rated voltage:	160 V
Material of the insulating body:	Thermoplastic
Rated current In:	8 A
Color:	black
Operating temperature:	-60 to 100 °C
QS fine-stranded:	0.2 to 1.5 mm²
QS single-stranded:	0.2 to 1.5 mm²
QS multi-stranded:	0.2 to 1.5 mm²
QS wire end ferrule:	0.25 to 1.5 mm²
Design of electrical connection 1:	Spring-loaded connection
Number of terminal points per pole:	1
Flammability class of the insulating material according to UL94:	V0
End plate required:	no
Explosion-tested version Ex e:	no
Transparent:	no
Width:	3.5 mm
Height:	7.8 mm
Depth:	23 mm
