Wago 714-170 THT pin header

In stock

SKU: 973297

Price on request

€4.70

€0

Overview

THT pin header, solder pin 0.8 x 0.8 mm, angled, pitch 3.5 mm, 10-pin, black

Property	Value
Number of plug contact rows:	1
Type of banding:	without
Type of PCB mounting:	Connection contact
Design of the electrical connection:	Solder connection
Mounting type:	soldering
Rated voltage:	160 V
Rated impulse voltage:	2.5 kV
Rated current In:	8 A
Operating temperature:	-60 to 100 °C
Flammability class of the insulating material according to UL94:	V0
Housing color:	black
Contact design:	pin
Pin length:	3.4 mm
Pitch of connections:	3.5 mm
Pitch of contacts:	3.5 mm
Connector design:	free connector
Overvoltage category:	III
Pollution level:	2
Material of contact coating:	tin
Material of insulating body:	thermoplastic
Angle circuit board/contact:	0°/180° (horizontal)
Connection type:	flexible PCB connector
Number of pins:	10
