Wago 721-176/003-000 R83.2mm, 16p, 250V terminal block

In stock

SKU: 968624

Price on request

€7.59

€0

Overview

Pin header for terminal blocks, pins 1.2 x 1.2 mm, straight, 100% protected against mismating, pitch 5 mm, 16-pin, light gray

Property	Value
Number of poles:	16
Rated voltage:	320 V
Material of the insulating body:	Thermoplastic
Rated current In:	16 A
Color:	gray
Operating temperature:	-60 to 100 °C
Design of electrical connection 1:	Spring-loaded connection
Design of electrical connection 2:	Spring-loaded connection
Number of terminal points per pole:	1
Flammability class of the insulating material according to UL94:	V0
End plate required:	no
Explosion-tested version Ex e:	no
Transparent:	no
Width:	5 mm
Height:	12 mm
Depth:	11.4 mm
