1-conductor female connector, angled, CAGE CLAMP®, 2.5 mm², pitch 7.5 mm, 6-pin, 100% protected against mismating, mounting flange, 2.50 mm², light gray
| Property | Value |
| Connectable cable type: | Round cable |
| Connectable conductor cross-section, single-wire: | 0.08 to 2.5 mm² |
| Connectable conductor cross-section, fine-stranded with wire end ferrule: | 0.25 to 1.5 mm² |
| Connectable conductor cross-section, fine-stranded without Wire end ferrule: | 0.08 to 2.5 mm² |
| Connectable conductor cross-section, stranded: | 0.08 to 2.5 mm² |
| Number of plug contact rows: | 1 |
| Design of the electrical connection: | Spring-loaded connection |
| Rated voltage: | 630 V |
| Rated impulse voltage: | 6 kV |
| Rated current In: | 12 A |
| Operating temperature: | -60 to 85 °C |
| Flammability class of the insulating material according to UL94: | V0 |
| Housing color: | gray |
| Contact design: | socket |
| With protective conductor: | no |
| Pitch of the connections: | 7.5 mm |
| Pitch of the contacts: | 7.5 mm |
| Protection class (IP), mounted: | IP20 |
| Overvoltage category: | III |
| Pollution level: | 2 |
| Material of the contact coating: | Tin |
| Material of the housing: | Plastic |
| Material of the insulating body: | Thermoplastic |
| Material of the contact: | Other copper alloys |
| Angle of contact/conductor connection: | 135° (obliquely upwards) |
| Connection type: | PCB to cable |
| Number of poles: | 6 |
| Housing coating: | uncoated |
