Wago 722-245/005-000 female connector 12A 15p Thermopl 5mm lgr

In stock

SKU: 972478

Price on request

€13.57

€0

Overview

Female connector for terminal blocks, pins 0.6 x 1 mm, angled, 100% protected against mismating, pitch 5 mm, 15-pin, light gray

Property	Value
Number of poles:	15
Rated voltage:	320 V
Material of the insulating body:	Thermoplastic
Rated current In:	12 A
Color:	gray
Operating temperature:	-60 to 85 °C
Design of electrical connection 1:	Spring-loaded connection
Design of electrical connection 2:	Spring-loaded connection
Number of terminal points per pole:	1
Flammability class of the insulating material according to UL94:	V0
End plate required:	no
Explosion-tested version Ex e:	no
Transparent:	no
Width:	5 mm
Height:	11.6 mm
Depth:	18.25 mm
