Wago 734-508/037-000 R3.81mm, 8p, 250V terminal block

In stock

SKU: 966939

Price on request

€5.41

€0

Overview

THT female connector, straight, pitch 3.81 mm, 8-pin, 100% protected against mismating, locking latch, solder pin 0.9 x 0.9 mm, orange

Property	Value
Number of plug contact rows:	1
Type of banding:	without
Type of PCB mounting:	Connection contact
Design of the electrical connection:	Solder connection
Mounting type:	soldering
Rated voltage:	160 V
Rated impulse voltage:	2.5 kV
Rated current In:	10 A
Operating temperature:	-60 to 100 °C
Flammability class of the insulating material according to UL94:	V0
Housing color:	orange
Contact design:	Pin
Length of pin:	3.8 mm
Connection pitch:	3.81 mm
Contact pitch:	3.81 mm
Connector design:	free connector
Overvoltage category:	III
Pollution level:	2
Contact coating material:	tin
Insulating body material:	thermoplastic
Angle PCB/Contact:	90° (vertical upwards)
Connection type:	flexible PCB connector
Number of pins:	8
