Wago 756-3100/000-250 25m PLC connection cable

In stock
SKU: 967406
€141.94
Into a basketIn the basketGo

Overview

Power cable, 4-pole, 4-pole, length 25 m

Property Value
Number of cores: 4
Outer Ø approx.: 6.2 mm
Nominal conductor cross-section: 0.75 mm²
Stranding element: no
Core marking: Color
Sheath color: gray
Conductor class: Class 5 = fine-wire
Shield over stranding element: without
Category: other
Shield over stranding: without
Sheath material: Polyurethane (PUR)
Permissible external cable temperature after installation without vibration: -30 to 80 °C
Conductor surface: bare
Permissible Cable external temperature during assembly/handling: -30 to 80 °C
Specification of conductor insulation: Polyethylene (PE)
UV-resistant: yes
Conductor material: copper
AWG size: 20
Core identification according to HD 308 S2: no
Permissible type of installation in the ground: other
Reinforcement/armoring: without
Reinforcement material: other
Cable geometry: round
Certified for marine applications: no
Separation class according to EN 50174-2: C
Suitable as a telephone cable: no
Suitable as a computer data cable: no
Suitable as a signal cable: no
Weight: 1450,000 kg/km
Compatible with Grade2TV according to XP-C 90-483: no
Compatible with Grade3TV according to XP-C 90-483: no

Characteristics

Sheath materialPolyurethane (PUR)
Nominal conductor cross-section0.75 mm²
CategoryOther
Conductor materialCopper
ManufacturerWago
HAN756-3100/000-250
GTIN4045454772338
AWG Size20
Wire number4
Weight1450,000 kg/km
Leader ClassKl.5 = fine-stranded
Coat colorGray
UV-resistantYes
Wago 756-3100/000-250 25m PLC connection cable
Wago 756-3100/000-250 25m PLC connection cable
€141.94
Into a basketIn the basketGo
