Wago 757-265/000-005 6pcs., 5p, 5m, M12 distributor sensor/actuator

In stock

SKU: 978789

Price on request

€157.39

€0

Overview

M12 sensor/actuator box, 6-way, 5-pin, 5 m

Property	Value
Number of sensor/actuator slots:	6
Length of the pre-assembled cable:	5 m
Number of pins of the sensor/actuator slots:	5
Protection class (IP):	IP68
Height:	26 mm
Width:	60 mm
Material of the contact base:	Brass
Connection for NPN sensors:	no
With potential separation:	no
With LED display:	yes
Degree of pollution:	3
Material of the contact coating:	Gold
Rated voltage:	32 V
Cable length configurable:	yes
Operating temperature:	-25 to 80 °C
Number of channels per slot:	6
Material of the insulating body:	Polyamide (PA)
Explosion protection category for dust:	without
Drag chain suitability of the fixed cable version:	yes
Design of the outlets for sensor/actuator cables:	M12
Material of the housing:	Plastic
Threaded sockets of the sensor/actuator slots:	M12
Operating voltage:	10 to 30 V
Explosion protection category for gas:	without
Max. current load per I/O signal:	2 A
Max. current load per connection socket:	9 A
Housing color:	gray
Depth:	123 mm
