Wago 771-8985/006-803 connection cable 5x1.5mm² BuSt, 8m, black

In stock

SKU: 976427

Price on request

€38.36

€0

Overview

prefabricated connecting cable, Eca, socket plug, 5-pin, code L, H05VV-F 5G 1.5 mm², 8 m, 1.50 mm², dark grey

Property	Value
Length:	8000 mm
Version side 1:	Socket
Version side 2:	Plug
Sheath colour:	black
Rated voltage:	400 V
Nominal conductor cross-section:	1.5 mm²
Rated impulse voltage:	6 kV
Voltage resistance:	1 mOhm
Housing color:	black
Protection class (IP):	IP20
Rated current:	16 A
Color of coding/contact insert:	other
Type of pre-assembled cable:	other
Degree of contamination:	3
Mechanical coding:	yes
Cable permanently temperature-resistant up to:	70 °C
Insulating part permanently temperature-resistant up to:	105 °C
Surface treatment of contacts:	tinned
Halogen-free:	no
Fire load:	66.96389 kWh
Number of poles:	5
Locking type:	separate
Cable diameter:	9.3 to 11.6 mm
Cable type:	H05VV-F
Max. operating temperature on conductor:	75 °C
Fire behavior according to EN 13501-6: Class:	Eca
