Wago 859-804 DC/DC converter

In stock

SKU: 521368

Price on request

€70.60

€0

Overview

DC-DC converter, input voltage DC 12 V, output voltage DC 24 V, output current 0.25 A, 2.50 mm², gray

Property	Value
Installation height:	56 mm
1. Output voltage:	24 V
Type of supply voltage:	DC
Max. Output current 1:	0.25 A
Output voltage adjustable:	no
Rated supply voltage for DC:	8 to 16 V
Short-circuit proof:	no
Stabilized:	no
Suitable for safety functions:	no
Direct mounting possible:	no
Design of the electrical connection:	Spring-loaded connection
Output voltage regulated:	yes
Power output:	6 W
Suitable for series installation:	yes
Rail mounting possible:	yes
Wall mounting possible:	no
Protection class (IP):	IP20
Width:	6 mm
Height:	56 mm
Depth:	91 mm
Nominal output voltage 1:	12 V
Nominal output current 1:	0.25 A
Width in pitch units:	0.33
