Comelit Group Germany 1596B 33V DC for door station 316 Touch power supply

In stock

SKU: 873578

Price on request

€273.83

€0

Overview

Power supply unit with 110-230V input voltage and 33V DC output voltage with 500mA continuous current and 1.2A short-term current for loudspeaker unit of the 316 Touch series. Equipped with internal protection against overvoltage and short circuits. Dimensions: 118x93x60.5mm (6 DIN modules).

Property	Value
Performance level according to EN ISO 13849-1:	without
1. Output voltage:	29.7 to 36.3 V
Type of supply voltage:	DC
Max. Output current 1:	1.82 A
Output voltage adjustable:	no
Rated supply voltage at AC 50 Hz:	88 to 264 V
Rated supply voltage at DC:	31 to 34 V
Short-circuit proof:	yes
Stabilized:	no
Suitable for safety functions:	no
Direct mounting possible:	no
Design of the electrical connection:	Screw/spring connection
Output voltage regulated:	no
Power consumption:	72 VA
Power output:	60 W
Suitable for series installation:	yes
Rail mounting possible:	yes
Wall mounting possible:	yes
Protection class (IP):	IP20
Width:	118 mm
Height:	93 mm
Depth:	62 mm
Nominal value output voltage 1:	33 V
Nominal output current 1:	0.9 A
Width in pitch units:	7
SIL according to IEC 61508:	without
