Dehn & Söhne 972146 Combined surge arrester DG ME DC Y 950 FM

In stock

SKU: 1029189

Price on request

€378.35

€0

Overview

Three-pole, modular, pluggable combined arrester type 1+2 DEHNguard ME DC Y 950 FM for direct current applications with mechanical operating state/fault indicator and UL approval. Arrester type 1+2 analogue to EN 61643-11, Y-circuit consisting of leakage-current-free varistor gas discharge technology. DC switching device DCD specially designed for use in DC circuits up to 950 V.

Property	Value
Lightning impulse current (10/350 µs):	5 kA
Test class:	Type 1 and 2
Number of poles:	3
Nominal voltage DC:	860 V
Size:	4 TE
Remote signaling:	yes
Signaling on the device:	optical
Network type DC:	yes
Maximum continuous voltage DC:	950 V
Mounting type:	DIN rail TH35
Protection level (DC+/DC- - PE):	3.2 kV
Max. conductor cross-section rigid (single/multi-wire):	35 mm²
Max. conductor cross-section flexible (fine-stranded):	25 mm²
Protection level (DC+ - DC-):	4 kV
Protection class (IP):	IP20
