Draka Comteq JV(ZN)H 2G BB-OM3 aqua fiber optic duplex cable 2x2.8mm

In stock
SKU: 899731
€0.72
Into a basketIn the basketGo

Overview

DIN designation: IV(ZN)H 2.8 fig.8 600N fiber optic cable as fig. 8 connection duplex version for structured cabling. The cable is metal-free with a tensile strength of 600N. The jacket is made of halogen-free, flame-retardant material according to IEC60332-1, IEC60332-3-24, IEC60754-1/2, IEC61034, EN50399 for use in public buildings with high risk to people according to Eurofire class Cca s1a d1 a1. Use as a flame-retardant cable indoors. The fiber optic cable exceeds the requirements of EN50173-1, ISO/IEC11801 and EN/IEC60794-2.

PropertyValue
Outer diameter approx.:2.8 mm
Sheath color:turquoise
Fiber type:Multimode 50/125
Core type:Full-loader
Number of fibers per core:1
With strain relief:yes
With rodent protection:no
Reinforcement:no
Sheath material:Polyolefins
Cable metal-free:yes
Flame-retardant:according to EN 60332-3-24
Low smoke according to EN 61034-2:yes
Functional integrity:no
Chemically resistant:no
Number of fibers:2
Halogen-free according to EN 60754-1/2:yes
Oil-resistant according to EN 60811-404:no
Category:OM3
Specification of sheath material:other
Cable longitudinally watertight:no
Cable transversely watertight:no
Fire behavior class according to EN 13501-6:Cca
Smoke development class according to EN 13501-6:s1a
Dripping behavior class according to EN 13501-6:d1
Acid development class according to EN 13501-6:a1
Min. permissible bending radius, stationary use/permanently installed:20 mm
Laying in the ground:no

Characteristics

Sheath materialPolyolefins
Outer diameter approx.2.8 mm
Oil-resistant according to EN 60811-404No
CategoryOM3
HABJV(ZN)H 2G BB-OM3 aqua
Minimal order100 meters
ManufacturerDraka Comteq
HAN60019440
GTIN4065624016864
Functional preservationNo
Coat colorTurquoise
With strain reliefYes
Draka Comteq JV(ZN)H 2G BB-OM3 aqua fiber optic duplex cable 2x2.8mm
Draka Comteq JV(ZN)H 2G BB-OM3 aqua fiber optic duplex cable 2x2.8mm
€0.72
Into a basketIn the basketGo
