JUMO 00374500 707021/888-888-22 0..100°C Pt100vl four-wire transmitter

In stock
SKU: 721129
€522.20
Into a basketIn the basketGo

Overview

The measuring transducer with 2 LEDs and 2 open collector outputs contains a microprocessor for digital signal processing. It can be mounted on a top hat rail. Screw terminals for stranded or wire (cable cross-section max. 2.5 mm) serve as the electrical connection. Power supply AC/DC 20 to 53 V. The measuring transducer can be configured using a setup program (available as an accessory) (example of adjustable parameters: sensor type, measuring range, output behavior, fine adjustment, customer-specific linearization). The dimensions are 22.5 x 109 x 118 mm.

Property Value
Design of the electrical connection: Screw connection
Width: 22.5 mm
Height: 109 mm
Depth: 124.8 mm
With removable terminals: no
Number of measuring circuits: 1
Error storage possible: no
External reset possible: no
Temperature measuring range: 0 to 100 °C

Characteristics

External reset possibleNo
HAB707021/888-888-22 0..100°C Pt100vl
ManufacturerJUMO
HAN00374500
GTIN4053877000617
Design of the electrical connectionScrew connection
Width22.5 mm
Height109 mm
With removable clampsNo
Depth124.8 mm
