Double-deck terminal, with additional cross-bridging on the ground floor, for mounting rail 35 x 15 and 35 x 7, 5, 2.5 mm², CAGE CLAMP®, 2.50 mm², grey/grey
| Property | Value |
| Colour: | grey |
| Connectable conductor cross-section, fine-stranded without wire end ferrule: | 0.08 to 2.5 mm² |
| Connectable conductor cross-section, stranded: | 0.08 to 2.5 mm² |
| Rated voltage: | 400 V |
| Number of levels: | 2 |
| Number of terminal points per level: | 2 |
| Rated current In: | 10 A |
| Operating temperature: | 105 °C |
| Connectable conductor cross-section, single-wire: | 0.08 to 2.5 mm² |
| Connectable conductor cross-section, fine-stranded with wire end ferrule: | 0.25 to 1.5 mm² |
| Design of electrical connection 1: | Spring-loaded connection |
| Design of electrical connection 2: | Spring-loaded connection |
| Mounting type: | DIN rail TH35 |
| Flammability class of the insulating material according to UL 94: | V0 |
| End plate required: | yes |
| Levels bridged internally: | no |
| Material of the insulating body: | Thermoplastic |
| Explosion-tested version 'Ex e': | no |
