Wago 2110-1304 lever and push-in CAGE CLAMP 10qmm blue 3 conductor feed-through terminal

In stock

SKU: 524708

Price on request

€5.88

€0

Overview

3-conductor feed-through terminal with lever and Push-in CAGE CLAMP® 10 mm with test opening suitable for Ex i applications side and center labeling for mounting rail 35 x 15 and 35 x 7.5 Push-in CAGE CLAMP®

Property	Value
Connection position:	top
Width/grid:	10 mm
Length:	110.4 mm
Height with lowest installation type:	36.9 mm
Color:	blue
Connectable conductor cross-section, fine-stranded without wire end ferrule:	16 mm
Connectable conductor cross-section, stranded:	16 mm
Rated voltage:	800 V
Number of levels:	1
Number of terminal points per level:	3
Rated current In:	57 A
Operating temperature:	110 °C
Connectable conductor cross-section, single-wire:	16 mm
Connectable conductor cross-section, finely stranded with wire end ferrule:	10 mm
Design of electrical connection 1:	Spring-loaded connection
Design of electrical connection 2:	Spring-loaded connection
Mounting type:	DIN rail TH35
Flammability class of the insulating material according to UL 94:	V0
End plate required:	yes
Levels bridged internally:	no
Material of the insulating body:	Thermoplastic
Explosion-tested version 'Ex e':	no
