Wago 769-112/022-000 angled 4qmm 12-pin 4.00qmm grey 1 conductor female connector

Wago 769-112/022-000 angled 4qmm 12-pin 4.00qmm grey 1 conductor female connector

In stock

SKU: 807328

Price on request

€14.77

€0

Into a basketIn the basketGo

Overview

769-112/022-000 angled 4qmm 12-pin 4.00qmm grey 1 conductor female connector Manufacturer article number: 769-112/022-000, Manufacturer article name: angled 4qmm 12-pin 4.00qmm grey

Property	Value
Number of poles:	12
Color:	grey
Rated voltage:	500 V
Material of the insulating body:	Thermoplastic
Rated current In:	32 A
Operating temperature:	105 °C
Connectable conductor cross-section, single-wire:	0.08 to 4 mm²
Connectable conductor cross-section, stranded:	0.08 to 4 mm²
Connectable conductor cross-section, fine-stranded with wire end ferrule:	0.25 to 2.5 mm²
Connectable conductor cross-section, fine-stranded without wire end ferrule:	0.08 to 4 mm²
Mounting type:	other
Design of electrical connection 1:	spring-loaded connection
Design of electrical connection 2:	spring-loaded connection
Number of terminal points per pole:	1
Flammability class of the insulating material according to UL 94:	V0
End plate required:	no
Explosion-tested version 'Ex e':	no
Transparent:	no

Characteristics

HABAngled 4qmm 12-pin 4.00qmm grey

Minimal order20 pcs

Manufacturer

HAN769-112/022-000

GTIN4044918547734

Connectable conductor cross-section solid0.08 to 4 mm²

Connectable conductor cross-section stranded0.08 to 4 mm²

Rated voltage500V

Rated current In32 A

Operating temperatur105°C

Flammability class of the insulating material according to UL 94V0

Color

Mounting typeOther

Number of poles12

TransparentNo
