Wago 264-737 grey 4 conductor mini protective conductor terminal

Wago 264-737 grey 4 conductor mini protective conductor terminal

In stock

SKU: 519342

Price on request

€2.37

€0

Into a basketIn the basketGo

Overview

4-conductor mini series terminal, 2.5 mm², center labeling, for mounting rail 35 x 15 and 35 x 7.5, CAGE CLAMP®, 2.50 mm², green-yellow

Property	Value
Operating temperature:	105 °C
Connectable conductor cross-section, single-wire:	0.08 to 2.5 mm²
Connectable conductor cross-section, stranded:	0.08 to 2.5 mm²
Connectable conductor cross-section, fine-stranded without wire end ferrule:	0.08 to 2.5 mm²
Connectable conductor cross-section, fine-stranded with wire end ferrule:	0.25 to 1.5 mm²
PEN function possible:	yes
Design of electrical connection 1:	spring-loaded connection
Design of electrical connection 2:	spring-loaded connection
Number of levels:	1
Number of terminal points per level:	4
Color:	green/yellow
Mounting type:	DIN rail TH35
Flammability class of the insulating material according to UL 94:	V0
End plate required:	yes
Material of the insulating body:	Thermoplastic

Characteristics

HAB264-737 grey

Minimal order100 pcs

Manufacturer

HAN264-737

GTIN4044918451956

Connectable conductor cross-section solid0.08 to 2.5 mm²

Connectable conductor cross-section stranded0.08 to 2.5 mm²

Operating temperatur105°C

Flammability class of the insulating material according to UL 94V0

Color

Mounting typeDIN rail TH35

Wago 264-737 grey 4 conductor mini protective conductor terminal

Wago 264-737 grey 4 conductor mini protective conductor terminal

Price on request

€2.37

€0

Into a basketIn the basketGo
